Developer Reference

A comprehensive guide for developers who want to contribute to Twin4Build. This guide will help you understand the codebase structure, development workflow, and how to contribute effectively.

Architecture Overview

Core Components

Twin4Build is organized around five main components which are exposed through the main module:

Model: Container for building systems, components, and connections
Simulator: Handles time-based simulations and time stepping
Translator: Generates models from semantic descriptions
Estimator: Performs parameter estimation and calibration
Optimizer: Optimizes building operation and control

The core—Model, Simulator, Estimator, Optimizer, Translator and their interactions—must remain stable and predictable. Adjacent modules (e.g., component models and GPU backends) extend the system but must respect explicit boundaries, documented contracts, and shared interfaces so contributors understand how their work interacts with the foundations.

Package Structure

twin4build/
├── core/           # Core functionality and base classes
├── model/          # Model components and building systems
├── simulator/      # Simulation engine and time stepping
├── translator/     # Semantic model translation
├── estimator/      # Parameter estimation and calibration
├── optimizer/      # Optimization algorithms
├── systems/        # Building system components
├── utils/          # Utility functions and helpers
├── examples/       # Example notebooks and scripts
└── tests/          # Test suite

Development Environment Setup

Prerequisites

Python 3.9 or higher (3.12 recommended)
Git
A code editor (VS Code, PyCharm, etc.)
Conda (recommended) or any Python environment manager

Quick Start: Use the automated setup script python scripts/setup_dev.py after cloning the repository for the fastest setup experience.

Installation from Source

Automated Setup (Recommended)

The easiest way to set up your development environment is using the provided setup script:

# Clone the repository
git clone https://github.com/JBjoernskov/Twin4Build.git
cd Twin4Build

# Run the automated setup script
python scripts/setup_dev.py

# Or with custom options
python scripts/setup_dev.py --python 3.12 --env t4bdev

What the setup script does:

Creates a conda environment with your specified Python version (default: 3.12)
Installs Twin4Build in development mode with all dependencies
Runs the test suite to verify installation
Provides clear next steps and available tools

Script options:

--python VERSION: Specify Python version (e.g., 3.9, 3.10, 3.11, 3.12)
--env NAME: Specify conda environment name (default: t4bdev)
--help: Show all available options

Manual Setup (Alternative)

If you prefer to set up manually or need a different environment manager:

# Clone the repository
git clone https://github.com/JBjoernskov/Twin4Build.git
cd Twin4Build

# Create conda environment
conda create -n t4bdev python=3.12
conda activate t4bdev

# Install in development mode with dependencies
pip install -e .[dev]

Alternative environment managers: You can also use venv, virtualenv, poetry, or pipenv - just ensure you have an isolated Python 3.9+ environment.

Code Style and Conventions

Python Style Guide

Follow PEP 8 style guidelines
Use type hints for function parameters and return values
Keep line length under 88 characters (Black formatter default)
Use meaningful variable and function names

Naming Conventions

Classes: PascalCase (e.g., Model, SpaceHeaterSystem)
Functions and variables: snake_case (e.g., run_simulation, temperature_data)
Module-level constants: UPPER_SNAKE_CASE (e.g., DEFAULT_TIMESTEP)
Private methods: prefix with underscore (e.g., _internal_calculation)
Private attributes: prefix with underscore (e.g., _components)
Keys used in System.input and System.output dictionaries: camelCase (e.g., indoorTemperature, co2Concentration)

Docstring Standards

Use Google-style docstrings and type hints:

def calculate_energy_consumption(self, temperature: float, duration: float) -> float:
    """Calculate energy consumption for a given temperature and duration.

    Args:
        temperature: The target temperature in Celsius
        duration: The duration in hours

    Returns:
        Energy consumption in kWh

    Raises:
        ValueError: If temperature is outside valid range
    """
    pass

For public class properties (acessed from outside the class), use the @property decorator:

class MyClass:
    @property
    def property_name(self) -> Any:
        """Description of the property."""
        return self._property_name

Avoid defining setter methods for public class properties unless necessary. This way, we avoid accidently changing the value of a property. If necessary, define a setter method for the property.

class MyClass:
    @property_name.setter
    def property_name(self, value: Any) -> None:
        """Description of the property."""
        self._property_name = value

Development Workflow

Branching Strategy

Twin4Build follows a disciplined branching model to keep development organized and reversible:

Main branch: Stable releases only, updated through approved merges from dev branch
Dev branch: Integration branch for completed features with tests and documentation
Feature branches: Each feature lives in its own branch containing only logically related changes
- Feature branches may have one level of sub-branching when needed
- Once complete, features merge into dev (never directly into main)
- Main contributors can make exemptions to this rule

Git Workflow

Create a GitHub issue describing the work to be done
Create a feature branch from dev:
```
git checkout dev
git pull origin dev
git checkout -b YY/issue-XX/description
```
Replace YY with the type of branch (feature, bugfix, docs) and XX with the issue number and description with a brief description.

Make your changes and commit with descriptive message using imperative mood:

git commit -m "Add new HVAC component for variable air volume systems"

Push your branch and create a pull request:

git push origin feature/issue-XX/description

Branch Naming Conventions

All branches must reference a GitHub issue and follow this pattern: type/issue-XX/description

feature/issue-XX/description: New features
bugfix/issue-XX/description: Bug fixes
docs/issue-XX/description: Documentation updates
test/issue-XX/description: Test additions or improvements
refactor/issue-XX/description: Code refactoring

Examples:

feature/issue-88/increase-test-coverage
bugfix/issue-42/fix-simulator-memory-leak
docs/issue-15/update-installation-guide

Definition of Done

A feature is considered “done” when:

Functionality meets the agreed scope
Code satisfies style guidelines (validated with python scripts/validate_code.py)
Tests (unit + integration) are included and pass
Documentation is updated
UML/architecture notes are provided when complexity requires it

This checklist ensures consistency, transparency, and predictable development velocity.

Pull Request Process

Run code validation: python scripts/validate_code.py
Run test suite locally: Ensure all tests pass before pushing
Update documentation if needed
Add tests for new functionality
Provide UML diagrams or architecture notes for moderately complex features
Add examples if applicable
Request review from maintainers

Note: A pull request is required for any changes made to main and dev branches.

Testing

Testing Strategy

Twin4Build aims for a practical balance: ensure stability without over-engineering.

Core Requirements:

All core features require component and integration tests to verify correctness of the Model→Simulator→Estimator→Optimizer chain
Public methods MUST have unit tests
Private methods CAN have unit tests for critical functionality
Adjacent modules should include targeted tests to validate their interfaces with the core
Before pushing to a branch, the test suite must be run locally to avoid pushing broken code

Tests serve two purposes: quality assurance and developer guidance, helping newcomers understand expected behavior.

Running Tests

Run the test suite using unittest:

python -m unittest discover twin4build/tests/

Run specific test files:

python -m unittest twin4build.tests.test_examples

Run with coverage:

coverage run -m unittest discover twin4build/tests/
coverage report
coverage html  # Generate HTML coverage report

Alternatively, you can use pytest which provides cleaner output and better reporting. pytest is fully compatible with unittest and requires no code changes.

Install pytest:

pip install pytest pytest-html pytest-cov

Run the test suite using pytest:

pytest twin4build/tests/

Run specific test files:

pytest twin4build/tests/systems/junction/test_junction_systems.py

Run with verbose output:

pytest twin4build/tests/ -v

Generate HTML test report:

pytest twin4build/tests/ --html=report.html --self-contained-html

Run with coverage:

pytest twin4build/tests/ --cov=twin4build --cov-report=html --cov-report=term-missing

Code Quality Validation

Before committing code, run the validation script to ensure your code meets Twin4Build standards:

Check code quality (recommended before every commit):

python scripts/validate_code.py

Auto-fix formatting issues:

python scripts/validate_code.py --fix

Include test suite in validation:

python scripts/validate_code.py --test

Combine options (fix issues and run tests):

python scripts/validate_code.py --fix --test

What the validation script checks:

Code formatting (Black): Ensures consistent code style
Import sorting (isort): Organizes import statements
Code style (flake8): Checks for style violations, syntax errors, unused variables, etc.
File issues: Trailing whitespace, missing newlines, etc.
Tests: Runs the full test suite

Manual tool usage (if needed):

# Format code
black .

# Sort imports (uses pyproject.toml config)
isort .

# Check style (uses .flake8 config)
flake8 .

Writing Tests

Use unittest framework for all tests:

import unittest
from twin4build import Model

class TestModel(unittest.TestCase):

    def setUp(self):
        """Set up test fixtures."""
        self.model = Model()

    def test_component_addition(self):
        """Test adding components to model."""
        component = self.create_test_component()
        self.model.add_component(component)
        self.assertIn(component, self.model.components)

    def test_simulation_run(self):
        """Test basic simulation execution."""
        result = self.model.simulate(start_time=0, end_time=100, step_size=1)
        self.assertIsNotNone(result)
        self.assertGreater(len(result), 0)

if __name__ == '__main__':
    unittest.main()

Test Organization

Organize tests using unittest’s test discovery patterns:

Test files: Named test_*.py
Test classes: Inherit from unittest.TestCase
Test methods: Start with test_

Advanced Testing Features

Use unittest’s advanced features for better testing:

class TestAdvanced(unittest.TestCase):

    @unittest.skipIf(condition, "reason")
    def test_conditional_skip(self):
        """Skip test based on condition."""
        pass

    @unittest.expectedFailure
    def test_known_failure(self):
        """Mark test as expected to fail."""
        pass

    def test_with_subtest(self):
        """Use subtests for parameterized testing."""
        test_cases = [1, 2, 3, 4]
        for case in test_cases:
            with self.subTest(case=case):
                self.assertTrue(case > 0)

Documentation

Documentation Standards

Keep documentation up to date with code changes
Include code examples for all public APIs
Use clear, concise language
Include diagrams and visual aids when helpful
Follow reStructuredText formatting for manual pages

Architecture Documentation

For moderately complex features, contributors should provide lightweight but effective architecture documentation:

Small UML-style diagrams or flow charts summarizing class interactions
Data flow diagrams when relevant
Component lifecycle documentation
Interface contracts and boundaries

This documentation supports knowledge transfer, helps reviewers rapidly understand intent, reduces onboarding friction, and prevents duplicate or conflicting design efforts.

Note: Features naturally change the architecture of the library over time. The goal of architecture documentation is not purely technical—it’s communicational: to define a ubiquitous language for developer onboarding and establish a traceable history of architectural decisions.

Building Documentation

Twin4Build uses Sphinx for documentation generation. The documentation build process requires two steps:

Step 1: Generate API Documentation

This step auto-generates API documentation from your Python docstrings:

cd docs

# On Windows:
.\make buildapi

# On Linux/Mac:
make buildapi

Step 2: Build HTML Documentation

This step compiles all documentation (manual + API) into HTML:

# On Windows:
.\make html

# On Linux/Mac:
make html

buildapi:

Scans your Python code for docstrings
Generates .rst files in source/auto/
Creates API reference documentation
Runs cleanup scripts

html: - Compiles all .rst files (manual + auto-generated) - Applies Sphinx theme - Generates final HTML documentation - Creates cross-references and search index

View Documentation

For viewing and browsing the documentation, open the Twin4Build/build/html/index.html file in your browser.

Writing Documentation

Manual Documentation: Edit files in docs/source/manual/

API Documentation: Add docstrings to your Python code:

def calculate_energy(temperature: float, duration: float) -> float:
    """Calculate energy consumption for given conditions.

    This function computes energy usage based on temperature
    and duration parameters for building simulation.

    Args:
        temperature: Target temperature in Celsius
        duration: Time duration in hours

    Returns:
        Energy consumption in kWh

    Example:
        >>> energy = calculate_energy(22.0, 8.0)
        >>> print(f"Energy used: {energy} kWh")
        Energy used: 24.5 kWh
    """
    return temperature * duration * 1.2

Troubleshooting Documentation Build

Common Issues:

Sphinx not found: Install dev dependencies with pip install -e .[dev]
Import errors in API docs: Ensure Twin4Build is installed in development mode
Missing modules: Check that all dependencies are installed
Build fails: Try cleaning first: delete docs/build/ and docs/source/auto/ directories

Clean Build:

# Remove generated files and rebuild
cd docs
rm -rf build/ source/auto/  # Linux/Mac
rmdir /s build source\auto  # Windows

# Then rebuild
make buildapi && make html  # Linux/Mac
.\make buildapi && .\make html  # Windows

Creating Examples

Use Jupyter notebooks for examples
Place examples in twin4build/examples/
Include both basic and advanced use cases
Ensure examples are self-contained and runnable
After adding an example, also add it to the test suite: twin4build/tests/test_examples.py

Contributing Guidelines

Reporting Bugs

Provide python version and operating system
Twin4Build version
Minimal code example to reproduce the issue
Expected vs. actual behavior
Error messages and stack traces

Suggesting Features

Describe the use case and motivation
Provide examples of how the feature would be used
Consider implementation complexity
Discuss potential impacts on existing functionality
Clearly distinguish whether the feature extends core functionality or is an adjacent module

Code Contribution Process

Fork the repository on GitHub
Create a feature branch following naming conventions
Make your changes following code style guidelines
Add examples (optional) for new functionality
Add tests for new functionality (required for public methods)
Update documentation as needed
Add architecture documentation if the feature is moderately complex
Run the test suite to ensure everything works
Submit a pull request with a clear description

Advanced Topics

Extending the Package

Creating Custom Components

To create a custom component:

Inherit from System and either Module or FMUSystem
Implement required methods
Add proper type hints and documentation
Include tests for your component

Example:

class CustomHVACComponent(System):
    """Custom HVAC component for specific use case."""

    def __init__(self, **kwargs):
        super().__init__(**kwargs)
        # Initialize component-specific attributes

    def initialize(self, start_time=None, end_time=None, step_size=None, simulator=None):
        super().__init__(**kwargs)
        # Initialize component-specific attributes

    def do_step(self, second_time, date_time, step_size, step_index):
        """Perform one simulation step."""
        # Implement simulation logic
        pass

Performance Considerations

Always use torch operations to enable automatic differentiation
Use vectorized operations when possible
Profile code to identify bottlenecks

Debugging Tips

Use logging for debugging information
Set breakpoints in your IDE
Use pdb for interactive debugging
Check component connections and data flow

Release Process

Version Management

Twin4Build follows semantic versioning (MAJOR.MINOR.PATCH) to maintain clarity for users and contributors:

MAJOR: Structural changes to the core or breaking interface updates
MINOR: New features or non-breaking improvements
PATCH: Hotfixes and stability updates

Version updates occur in both dev and main branches:

Every merge into the dev branch bumps the version number with a pre-release tag
Main branch receives version updates only for stable releases

Building and Distributing

Update version number in pyproject.toml
Run full test suite
Build documentation
Create release notes for significant changes
Tag releases in Git
Create distribution:
```
python -m build
```
Upload to PyPI (maintainers only)

Getting Help

GitHub Issues: For bug reports and feature requests
Documentation: Check the online docs first
Examples: Review the example notebooks
Code: Examine the source code and tests

Contact Information

Maintainer: Jakob Bjørnskov (jabj@mmmi.sdu.dk)
GitHub: https://github.com/JBjoernskov/Twin4Build/
Documentation: https://twin4build.readthedocs.io/
